GB/T17880.2 | M4*11
ModelM4*11
D₃Thread SizeM4
LBody Length · mm11
d0 minMounting Hole Min · mm4.9
d0 maxMounting Hole Max · mm5.1
g minGrip Range Min · mm1.5
MOQ10000
1/3Rivets （铆接系列）
Threaded Insert GB/T17880.2
GB/T17880.2 · Carbon Steel
- Material
- Carbon Steel
- Finish
- Zinc Plated
MOQ: 5000–10000 pcs
Share
Available options
Material
Finish
6 sizes
| Model | D₃Thread Size | LBody Length · mm | d0 minMounting Hole Min · mm | d0 maxMounting Hole Max · mm | g minGrip Range Min · mm | MOQ | Quantity and inquiry |
|---|---|---|---|---|---|---|---|
| M4*11 | M4 | 11 | 4.9 | 5.1 | 1.5 | 10000 | |
| M5*13 | M5 | 13 | 5.9 | 6.1 | 1.5 | 10000 | |
| M6*15.5 | M6 | 15.5 | 6.9 | 7.1 | 1.5 | 10000 | |
| M8*17 | M8 | 17 | 8.9 | 9.1 | 1.5 | 5000 | |
| M10*19 | M10 | 19 | 10.9 | 11.1 | 2.0 | 5000 | |
| M12*22 | M12 | 22 | 12.9 | 13.1 | 2.0 | 5000 |
GB/T17880.2 | M5*13
ModelM5*13
D₃Thread SizeM5
LBody Length · mm13
d0 minMounting Hole Min · mm5.9
d0 maxMounting Hole Max · mm6.1
g minGrip Range Min · mm1.5
MOQ10000
GB/T17880.2 | M6*15.5
ModelM6*15.5
D₃Thread SizeM6
LBody Length · mm15.5
d0 minMounting Hole Min · mm6.9
d0 maxMounting Hole Max · mm7.1
g minGrip Range Min · mm1.5
MOQ10000
GB/T17880.2 | M8*17
ModelM8*17
D₃Thread SizeM8
LBody Length · mm17
d0 minMounting Hole Min · mm8.9
d0 maxMounting Hole Max · mm9.1
g minGrip Range Min · mm1.5
MOQ5000
GB/T17880.2 | M10*19
ModelM10*19
D₃Thread SizeM10
LBody Length · mm19
d0 minMounting Hole Min · mm10.9
d0 maxMounting Hole Max · mm11.1
g minGrip Range Min · mm2.0
MOQ5000
GB/T17880.2 | M12*22
ModelM12*22
D₃Thread SizeM12
LBody Length · mm22
d0 minMounting Hole Min · mm12.9
d0 maxMounting Hole Max · mm13.1
g minGrip Range Min · mm2.0
MOQ5000
Product description
Threaded Insert GB/T17880.2 is a carbon steel rivet nut with zinc plating, supplied in six confirmed sizes: M4×11, M5×13, M6×15.5, M8×17, M10×19, and M12×22.
Key features
- Provides a reusable machine thread in thin or soft material; set into a plain pilot hole.
Applications
- Used for providing reusable threads in thin or soft materials, sheet metal and plastic housings, and repairing stripped threads.
Standard and order documents
The selected execution standard is the product basis. Published or order-specific documents are shown only when they have been confirmed for this product.
Order assurance
Available options; exact scope is fixed in the quotation or order.EN 10204 3.1 material certificate
Can be included when agreed in the order.
Dimensional inspection report
Can be provided for the agreed inspection scope.
Bulk carton packing
Available subject to confirmed piece weight and shipping requirements.
Palletized shipment
Available when pallet size and handling requirements are confirmed.
Small boxes with outer cartons
Available when the box quantity and labels are agreed.
Buyer branding and labels
Available after artwork, label content, placement and the applicable minimum batch are agreed.
Frequently Asked Questions
What documented quality support is available for Threaded Insert GB/T17880.2?
Documents: EN 10204 3.1 material certificate, Dimensional inspection report. Confirm the required scope and acceptance criteria in the quotation.
Which order and delivery details are already confirmed for Threaded Insert GB/T17880.2?
MOQ: 5000–10000 pcs. Confirmed packing options include Bulk carton packing, Palletized shipment, Small boxes with outer cartons, Buyer branding and labels.
What information should be included in a quotation request for Threaded Insert GB/T17880.2?
Provide the required standard, material, finish, quantity, delivery destination.
