DIN 582 | M6
dNominal Diameter · mmM6
PThread Pitch · mm1
d2Base Diameter · mm20
d3Eye Outside Diameter · mm36
d4Eye Inside Diameter · mm20
eBase Height · mm8.5
MOQ10000
1/2Nuts
Eye Nut
DIN 582 · M6–M20 · Carbon Steel, Stainless Steel
● Available for quotation
- Material
- Carbon Steel, Stainless Steel
- Product Type
- Lifting Eye Nut
MOQ: 10000 pcs
Share
Available options
Material
Grade
Carbon Steel
Stainless Steel
Finish
6 sizes
| dNominal Diameter · mm | PThread Pitch · mm | d2Base Diameter · mm | d3Eye Outside Diameter · mm | d4Eye Inside Diameter · mm | eBase Height · mm | MOQ | Quantity and inquiry |
|---|---|---|---|---|---|---|---|
| M6 | 1 | 20 | 36 | 20 | 8.5 | 10000 | |
| M8 | 1.25 | 20 | 36 | 20 | 8.5 | 10000 | |
| M10 | 1.5 | 25 | 45 | 25 | 10 | 10000 | |
| M12 | 1.75 | 30 | 54 | 30 | 11 | 10000 | |
| M16 | 2 | 35 | 63 | 35 | 13 | 10000 | |
| M20 | 2.5 | 40 | 72 | 40 | 16 | 10000 |
DIN 582 | M8
dNominal Diameter · mmM8
PThread Pitch · mm1.25
d2Base Diameter · mm20
d3Eye Outside Diameter · mm36
d4Eye Inside Diameter · mm20
eBase Height · mm8.5
MOQ10000
DIN 582 | M10
dNominal Diameter · mmM10
PThread Pitch · mm1.5
d2Base Diameter · mm25
d3Eye Outside Diameter · mm45
d4Eye Inside Diameter · mm25
eBase Height · mm10
MOQ10000
DIN 582 | M12
dNominal Diameter · mmM12
PThread Pitch · mm1.75
d2Base Diameter · mm30
d3Eye Outside Diameter · mm54
d4Eye Inside Diameter · mm30
eBase Height · mm11
MOQ10000
DIN 582 | M16
dNominal Diameter · mmM16
PThread Pitch · mm2
d2Base Diameter · mm35
d3Eye Outside Diameter · mm63
d4Eye Inside Diameter · mm35
eBase Height · mm13
MOQ10000
DIN 582 | M20
dNominal Diameter · mmM20
PThread Pitch · mm2.5
d2Base Diameter · mm40
d3Eye Outside Diameter · mm72
d4Eye Inside Diameter · mm40
eBase Height · mm16
MOQ10000
Product description
Eye Nut is supplied to DIN 582 in M6–M20 diameters. Confirmed supply options include Carbon Steel and Stainless Steel, grades or classes 04 and A2-70, Zinc Plated and Plain finishes.
Key features
- Hexagon form driven by standard spanners and sockets.
Applications
- Suitable for general bolted assembly, steel structure connections, and machinery and equipment assembly.
Standard and order documents
The selected execution standard is the product basis. Published or order-specific documents are shown only when they have been confirmed for this product.
Order assurance
Available options; exact scope is fixed in the quotation or order.Dimensional inspection report
Can be provided for the agreed inspection scope.
Bulk carton packing
Available subject to confirmed piece weight and shipping requirements.
Palletized shipment
Available when pallet size and handling requirements are confirmed.
Small boxes with outer cartons
Available when the box quantity and labels are agreed.
Buyer branding and labels
Available after artwork, label content, placement and the applicable minimum batch are agreed.
Frequently Asked Questions
What documented quality support is available for Eye Nut?
Documents: Dimensional inspection report. Confirm the required scope and acceptance criteria in the quotation.
Which order and delivery details are already confirmed for Eye Nut?
MOQ: 10000 pcs. Confirmed packing options include Bulk carton packing, Palletized shipment, Small boxes with outer cartons, Buyer branding and labels.
What information should be included in a quotation request for Eye Nut?
Provide the required standard, diameter or size, material, property class or grade, finish, quantity, delivery destination.
