GB/T 15856.1 | ST2.9 x 13
dNominal Diameter · mmST2.9
lLength · mm13
Recess Number1
tDrilling Capacity (min) · mm0.7
tDrilling Capacity (max) · mm1.9
PThread Pitch · mm1.1
MOQ30000
Screws
Pan head cross-recessed drilling screws with tapping thread
GB/T 15856.1 · ST2.9, ST3.5, ST4.2 and other confirmed options · Stainless Steel, Carbon Steel
GB/T 15856.1 (Current)Corresponding standard: ISO 15481
● Made to order
- Drive
- Cross Recess
- Material
- Stainless Steel, Carbon Steel
- Head Style
- Pan Head
- Thread Type
- Self-Drilling Thread
MOQ: 10000–30000 pcs
Share
Available options
Material
Finish
37 sizes
| dNominal Diameter · mm | lLength · mm | Recess Number | tDrilling Capacity (min) · mm | tDrilling Capacity (max) · mm | PThread Pitch · mm | MOQ | Quantity and inquiry |
|---|---|---|---|---|---|---|---|
| ST2.9 | 13 | 1 | 0.7 | 1.9 | 1.1 | 30000 | |
| ST2.9 | 16 | 1 | 0.7 | 1.9 | 1.1 | 30000 | |
| ST2.9 | 19 | 1 | 0.7 | 1.9 | 1.1 | 30000 | |
| ST3.5 | 13 | 2 | 0.7 | 2.25 | 1.3 | 10000 | |
| ST3.5 | 16 | 2 | 0.7 | 2.25 | 1.3 | 10000 | |
| ST3.5 | 19 | 2 | 0.7 | 2.25 | 1.3 | 10000 | |
| ST3.5 | 25 | 2 | 0.7 | 2.25 | 1.3 | 10000 | |
| ST3.5 | 32 | 2 | 0.7 | 2.25 | 1.3 | 10000 | |
| ST4.2 | 13 | 2 | 1.75 | 3 | 1.4 | 10000 | |
| ST4.2 | 16 | 2 | 1.75 | 3 | 1.4 | 10000 | |
| ST4.2 | 19 | 2 | 1.75 | 3 | 1.4 | 10000 | |
| ST4.2 | 25 | 2 | 1.75 | 3 | 1.4 | 10000 | |
| ST4.2 | 32 | 2 | 1.75 | 3 | 1.4 | 10000 | |
| ST4.2 | 38 | 2 | 1.75 | 3 | 1.4 | 10000 | |
| ST4.8 | 13 | 2 | 1.75 | 4.4 | 1.6 | 10000 | |
| ST4.8 | 16 | 2 | 1.75 | 4.4 | 1.6 | 10000 |
GB/T 15856.1 | ST2.9 x 16
dNominal Diameter · mmST2.9
lLength · mm16
Recess Number1
tDrilling Capacity (min) · mm0.7
tDrilling Capacity (max) · mm1.9
PThread Pitch · mm1.1
MOQ30000
GB/T 15856.1 | ST2.9 x 19
dNominal Diameter · mmST2.9
lLength · mm19
Recess Number1
tDrilling Capacity (min) · mm0.7
tDrilling Capacity (max) · mm1.9
PThread Pitch · mm1.1
MOQ30000
GB/T 15856.1 | ST3.5 x 13
dNominal Diameter · mmST3.5
lLength · mm13
Recess Number2
tDrilling Capacity (min) · mm0.7
tDrilling Capacity (max) · mm2.25
PThread Pitch · mm1.3
MOQ10000
GB/T 15856.1 | ST3.5 x 16
dNominal Diameter · mmST3.5
lLength · mm16
Recess Number2
tDrilling Capacity (min) · mm0.7
tDrilling Capacity (max) · mm2.25
PThread Pitch · mm1.3
MOQ10000
GB/T 15856.1 | ST3.5 x 19
dNominal Diameter · mmST3.5
lLength · mm19
Recess Number2
tDrilling Capacity (min) · mm0.7
tDrilling Capacity (max) · mm2.25
PThread Pitch · mm1.3
MOQ10000
GB/T 15856.1 | ST3.5 x 25
dNominal Diameter · mmST3.5
lLength · mm25
Recess Number2
tDrilling Capacity (min) · mm0.7
tDrilling Capacity (max) · mm2.25
PThread Pitch · mm1.3
MOQ10000
GB/T 15856.1 | ST3.5 x 32
dNominal Diameter · mmST3.5
lLength · mm32
Recess Number2
tDrilling Capacity (min) · mm0.7
tDrilling Capacity (max) · mm2.25
PThread Pitch · mm1.3
MOQ10000
GB/T 15856.1 | ST4.2 x 13
dNominal Diameter · mmST4.2
lLength · mm13
Recess Number2
tDrilling Capacity (min) · mm1.75
tDrilling Capacity (max) · mm3
PThread Pitch · mm1.4
MOQ10000
GB/T 15856.1 | ST4.2 x 16
dNominal Diameter · mmST4.2
lLength · mm16
Recess Number2
tDrilling Capacity (min) · mm1.75
tDrilling Capacity (max) · mm3
PThread Pitch · mm1.4
MOQ10000
GB/T 15856.1 | ST4.2 x 19
dNominal Diameter · mmST4.2
lLength · mm19
Recess Number2
tDrilling Capacity (min) · mm1.75
tDrilling Capacity (max) · mm3
PThread Pitch · mm1.4
MOQ10000
GB/T 15856.1 | ST4.2 x 25
dNominal Diameter · mmST4.2
lLength · mm25
Recess Number2
tDrilling Capacity (min) · mm1.75
tDrilling Capacity (max) · mm3
PThread Pitch · mm1.4
MOQ10000
GB/T 15856.1 | ST4.2 x 32
dNominal Diameter · mmST4.2
lLength · mm32
Recess Number2
tDrilling Capacity (min) · mm1.75
tDrilling Capacity (max) · mm3
PThread Pitch · mm1.4
MOQ10000
GB/T 15856.1 | ST4.2 x 38
dNominal Diameter · mmST4.2
lLength · mm38
Recess Number2
tDrilling Capacity (min) · mm1.75
tDrilling Capacity (max) · mm3
PThread Pitch · mm1.4
MOQ10000
GB/T 15856.1 | ST4.8 x 13
dNominal Diameter · mmST4.8
lLength · mm13
Recess Number2
tDrilling Capacity (min) · mm1.75
tDrilling Capacity (max) · mm4.4
PThread Pitch · mm1.6
MOQ10000
GB/T 15856.1 | ST4.8 x 16
dNominal Diameter · mmST4.8
lLength · mm16
Recess Number2
tDrilling Capacity (min) · mm1.75
tDrilling Capacity (max) · mm4.4
PThread Pitch · mm1.6
MOQ10000
Product description
Pan head cross-recessed drilling screws with tapping thread is supplied to GB/T 15856.1 in 13–50 mm lengths. Confirmed supply options include Stainless Steel and Carbon Steel, Plain and Zinc Plated finishes.
Key features
- Drill point pierces the substrate without pre-drilling.
Applications
- Suitable for metal roofing and wall cladding, steel purlin and light gauge steel framing, and HVAC ducting.
Standard and order documents
The selected execution standard is the product basis. Published or order-specific documents are shown only when they have been confirmed for this product.
Order assurance
Available options; exact scope is fixed in the quotation or order.EN 10204 3.1 material certificate
Can be included when agreed in the order.
Dimensional inspection report
Can be provided for the agreed inspection scope.
Bulk carton packing
Available subject to confirmed piece weight and shipping requirements.
Palletized shipment
Available when pallet size and handling requirements are confirmed.
Small boxes with outer cartons
Available when the box quantity and labels are agreed.
Buyer branding and labels
Available after artwork, label content, placement and the applicable minimum batch are agreed.
Frequently Asked Questions
What documented quality support is available for Pan head cross-recessed drilling screws with tapping thread?
Documents: EN 10204 3.1 material certificate, Dimensional inspection report. Confirm the required scope and acceptance criteria in the quotation.
Which order and delivery details are already confirmed for Pan head cross-recessed drilling screws with tapping thread?
MOQ: 10000–30000 pcs. Confirmed packing options include Bulk carton packing, Palletized shipment, Small boxes with outer cartons, Buyer branding and labels.
What information should be included in a quotation request for Pan head cross-recessed drilling screws with tapping thread?
Provide the required standard, diameter or size, length, material, finish, quantity, delivery destination.
