Bulk carton packing
Available subject to confirmed piece weight and shipping requirements.
1/2Bolts
Lifting Eye Bolt
DIN 580 · M6–M24 · Stainless Steel, Carbon Steel
- Material
- Stainless Steel, Carbon Steel
- Product Type
- Lifting Eye Bolt
MOQ: 5000–10000 pcs
Share
Available with the order
Order assurance
The supplier has confirmed that the options below can be agreed for this product. The exact scope is fixed in the quotation or order.Palletized shipment
Available when pallet size and handling requirements are confirmed.
Small boxes with outer cartons
Available when the box quantity and labels are agreed.
Buyer-specified labels
Available after label content and placement are approved.
Available options
Material
Grade
Stainless Steel
Carbon Steel
Finish
7 sizes
| d | P | d2 | d3 | d4 | e | MOQ | Quantity and inquiry |
|---|---|---|---|---|---|---|---|
| M6 | 1 | 20 | 36 | 20 | 6 | 10000 | |
| M8 | 1.25 | 20 | 36 | 20 | 6 | 5000 | |
| M10 | 1.5 | 25 | 45 | 25 | 8 | 5000 | |
| M12 | 1.75 | 30 | 54 | 30 | 10 | 5000 | |
| M16 | 2 | 35 | 63 | 35 | 12 | 5000 | |
| M20 | 2.5 | 40 | 72 | 40 | 14 | 5000 | |
| M24 | 3 | 50 | 90 | 50 | 18 | 5000–10000 pcs |
DIN 580 | M6
dM6
P1
d220
d336
d420
e6
MOQ10000
DIN 580 | M8
dM8
P1.25
d220
d336
d420
e6
MOQ5000
DIN 580 | M10
dM10
P1.5
d225
d345
d425
e8
MOQ5000
DIN 580 | M12
dM12
P1.75
d230
d354
d430
e10
MOQ5000
DIN 580 | M16
dM16
P2
d235
d363
d435
e12
MOQ5000
DIN 580 | M20
dM20
P2.5
d240
d372
d440
e14
MOQ5000
DIN 580 | M24
dM24
P3
d250
d390
d450
e18
MOQ5000–10000 pcs
Product description
DIN 580 lifting eye bolt for lifting and lashing applications. Supplied in stainless steel (A2-70) or carbon steel (grades 4.8 and 12.9) with plain, blackened, or zinc plated finishes. Sizes from M6 to M24 with metric coarse threads. Specify diameter, material grade, finish, and quantity for quotation.
Key features
- Available in stainless steel A2-70 and carbon steel grades 4.8 and 12.9
- Finishes include plain, blackened, and zinc plated
- Sizes from M6 to M24 with metric coarse threads
Standard and order documents
The selected execution standard is the product basis. Published or order-specific documents are shown only when they have been confirmed for this product.
Frequently Asked Questions
What standards and sizes are available for Lifting Eye Bolt?
Execution standard: DIN 580. The confirmed specification table covers M6–M24 diameters. Use the specification table to select the exact variant required for quotation.
What materials and product options are available for Lifting Eye Bolt?
Material: Stainless Steel, Carbon Steel. Availability should be confirmed against the selected specification and order quantity.
What are the order, packing and sample terms for Lifting Eye Bolt?
MOQ: 5000–10000 pcs. Confirmed packing options include Bulk carton packing, Palletized shipment, Small boxes with outer cartons, Buyer-specified labels.
What information should be included in a quotation request for Lifting Eye Bolt?
Please provide the required standard, diameter or size, material, quantity, delivery destination. A drawing or sample reference is useful when the requirement is non-standard.
