M6 × 1
d · mmM6
P · mm1
s · mm10
e · mm11.05
m · mm5
Weight · kg/10002.53
MOQ100
1/2Nuts
DIN 934 Hexagon Nuts
DIN 934 carbon steel hexagon nuts, property class 8, black oxide finish.
● Available for quotation
- Standard
- DIN 934 (Historical)
- Material
- Carbon Steel
- Property Class
- 8
- Finish
- Black Oxide
- Nut Type
- Hexagon Nut
MOQ: 100 · Lead time: 10
Share
| d · mm | P · mm | s · mm | e · mm | m · mm | Weight · kg/1000 | MOQ | Quantity / Add |
|---|---|---|---|---|---|---|---|
| M6 | 1 | 10 | 11.05 | 5 | 2.53 | 100 | |
| M8 | 1.25 | 13 | 14.38 | 6.5 | 5.48 | 100 | |
| M10 | 1.5 | 17 | 18.9 | 8 | 11.81 | 100 | |
| M12 | 1.75 | 19 | 21.1 | 10 | 17.73 | 100 | |
| M16 | 2 | 24 | 26.75 | 13 | 35.51 | 100 | |
| M20 | 2.5 | 30 | 33.53 | 16 | 68.28 | 100 | |
| M24 | 3 | 36 | 39.98 | 19 | 116.77 | 100 | |
| M30 | 3.5 | 46 | 50.85 | 24 | 244.41 | 100 | |
| M36 | 4 | 55 | 60.79 | 29 | 421.20 | 100 |
M8 × 1.25
d · mmM8
P · mm1.25
s · mm13
e · mm14.38
m · mm6.5
Weight · kg/10005.48
MOQ100
M10 × 1.5
d · mmM10
P · mm1.5
s · mm17
e · mm18.9
m · mm8
Weight · kg/100011.81
MOQ100
M12 × 1.75
d · mmM12
P · mm1.75
s · mm19
e · mm21.1
m · mm10
Weight · kg/100017.73
MOQ100
M16 × 2
d · mmM16
P · mm2
s · mm24
e · mm26.75
m · mm13
Weight · kg/100035.51
MOQ100
M20 × 2.5
d · mmM20
P · mm2.5
s · mm30
e · mm33.53
m · mm16
Weight · kg/100068.28
MOQ100
M24 × 3
d · mmM24
P · mm3
s · mm36
e · mm39.98
m · mm19
Weight · kg/1000116.77
MOQ100
M30 × 3.5
d · mmM30
P · mm3.5
s · mm46
e · mm50.85
m · mm24
Weight · kg/1000244.41
MOQ100
M36 × 4
d · mmM36
P · mm4
s · mm55
e · mm60.79
m · mm29
Weight · kg/1000421.20
MOQ100
Product description
These hexagon nuts are manufactured in accordance with DIN 934, a widely recognized standard for hexagon nuts. They are made from carbon steel and feature a black oxide finish. The property class is 8, indicating a specific hardness and strength level as defined by the standard. Available sizes range from M6 to M36, with corresponding pitch, width across flats (s), width across corners (e), and nut height (m) dimensions as specified in the standard. The nuts are designed for general fastening applications where a hexagon nut is required.
Key features
- Manufactured to DIN 934
- Carbon steel material
- Black oxide finish
- Property class 8
Related Products
Frequently Asked Questions
What standards and sizes are available for DIN 934 Hexagon Nuts?
Available execution standards include DIN 934, DIN 934 / ISO 4032 / GB/T 6170. The confirmed specification table covers M6–M36 diameters. Use the specification table to select the exact variant required for quotation.
What materials and product options are available for DIN 934 Hexagon Nuts?
Material: Carbon Steel; Finish: Black Oxide; Property Class: 8. Availability should be confirmed against the selected specification and order quantity.
What information should be included in a quotation request for DIN 934 Hexagon Nuts?
Please provide the required standard, diameter or size, material, property class or grade, finish, quantity, delivery destination. A drawing or sample reference is useful when the requirement is non-standard.
