M4 × 40
d · mmM4
l · mm40
P · mm0.7
s · mm3
dk · mm7
k · mm4
Weight · kg/10004.61
MOQ100 pcs
Screws
Hexagon Socket Head Cap Screw DIN 912 ISO 4762
Hexagon Socket Head Cap Screw DIN 912, 40Cr Alloy Steel, Property Class 12.9, Black Oxide.
● Available for quotation
- Standard
- DIN 912 (Historical)
- Head Form
- Cylindrical Head
- Drive
- Hexagon Socket
- Material
- 40Cr Alloy Steel
- Property Class
- 12.9
- Finish
- Black Oxide
MOQ: 100 pcs · Lead time: 10 Days
Share
| d · mm | l · mm | P · mm | s · mm | dk · mm | k · mm | Weight · kg/1000 | MOQ | Quantity / Add |
|---|---|---|---|---|---|---|---|---|
| M4 | 40 | 0.7 | 3 | 7 | 4 | 4.61 | 100 pcs | |
| M4 | 50 | 0.7 | 3 | 7 | 4 | 5.53 | 100 pcs | |
| M6 | 12 | 1 | 5 | 10 | 6 | 5.36 | 100 pcs | |
| M6 | 16 | 1 | 5 | 10 | 6 | 6.19 | 100 pcs | |
| M6 | 20 | 1 | 5 | 10 | 6 | 7.01 | 100 pcs | |
| M6 | 25 | 1 | 5 | 10 | 6 | 8.05 | 100 pcs | |
| M6 | 30 | 1 | 5 | 10 | 6 | 9.08 | 100 pcs | |
| M6 | 35 | 1 | 5 | 10 | 6 | 10.11 | 100 pcs | |
| M6 | 40 | 1 | 5 | 10 | 6 | 11.14 | 100 pcs | |
| M6 | 45 | 1 | 5 | 10 | 6 | 12.17 | 100 pcs | |
| M6 | 50 | 1 | 5 | 10 | 6 | 13.21 | 100 pcs | |
| M6 | 55 | 1 | 5 | 10 | 6 | 14.24 | 100 pcs | |
| M6 | 60 | 1 | 5 | 10 | 6 | 15.27 | 100 pcs | |
| M8 | 12 | 1.25 | 6 | 13 | 8 | 10.91 | 100 pcs | |
| M8 | 16 | 1.25 | 6 | 13 | 8 | 12.37 | 100 pcs | |
| M8 | 20 | 1.25 | 6 | 13 | 8 | 13.84 | 100 pcs |
M4 × 50
d · mmM4
l · mm50
P · mm0.7
s · mm3
dk · mm7
k · mm4
Weight · kg/10005.53
MOQ100 pcs
M6 × 12
d · mmM6
l · mm12
P · mm1
s · mm5
dk · mm10
k · mm6
Weight · kg/10005.36
MOQ100 pcs
M6 × 16
d · mmM6
l · mm16
P · mm1
s · mm5
dk · mm10
k · mm6
Weight · kg/10006.19
MOQ100 pcs
M6 × 20
d · mmM6
l · mm20
P · mm1
s · mm5
dk · mm10
k · mm6
Weight · kg/10007.01
MOQ100 pcs
M6 × 25
d · mmM6
l · mm25
P · mm1
s · mm5
dk · mm10
k · mm6
Weight · kg/10008.05
MOQ100 pcs
M6 × 30
d · mmM6
l · mm30
P · mm1
s · mm5
dk · mm10
k · mm6
Weight · kg/10009.08
MOQ100 pcs
M6 × 35
d · mmM6
l · mm35
P · mm1
s · mm5
dk · mm10
k · mm6
Weight · kg/100010.11
MOQ100 pcs
M6 × 40
d · mmM6
l · mm40
P · mm1
s · mm5
dk · mm10
k · mm6
Weight · kg/100011.14
MOQ100 pcs
M6 × 45
d · mmM6
l · mm45
P · mm1
s · mm5
dk · mm10
k · mm6
Weight · kg/100012.17
MOQ100 pcs
M6 × 50
d · mmM6
l · mm50
P · mm1
s · mm5
dk · mm10
k · mm6
Weight · kg/100013.21
MOQ100 pcs
M6 × 55
d · mmM6
l · mm55
P · mm1
s · mm5
dk · mm10
k · mm6
Weight · kg/100014.24
MOQ100 pcs
M6 × 60
d · mmM6
l · mm60
P · mm1
s · mm5
dk · mm10
k · mm6
Weight · kg/100015.27
MOQ100 pcs
M8 × 12
d · mmM8
l · mm12
P · mm1.25
s · mm6
dk · mm13
k · mm8
Weight · kg/100010.91
MOQ100 pcs
M8 × 16
d · mmM8
l · mm16
P · mm1.25
s · mm6
dk · mm13
k · mm8
Weight · kg/100012.37
MOQ100 pcs
M8 × 20
d · mmM8
l · mm20
P · mm1.25
s · mm6
dk · mm13
k · mm8
Weight · kg/100013.84
MOQ100 pcs
199 Product Specifications
Page 1/13
Product description
This hexagon socket head cap screw is manufactured to DIN 912 standard from 40Cr alloy steel. It features a black oxide finish and is available in property class 12.9. The hex socket drive allows for secure tightening with standard hex keys. Specification samples include M4, M6, and M8 diameters with various lengths. Key dimensions such as head height (k), head diameter (dk), and socket size are provided per DIN 912. Additional sizes and lengths are available to customer specification.
Key features
- Manufactured to DIN 912 standard
- 40Cr alloy steel
- Black oxide finish
- Property class 12.9
Related Products
Frequently Asked Questions
What standards and sizes are available for Hexagon Socket Head Cap Screw DIN 912 ISO 4762?
Available execution standards include DIN 912, DIN 912 / ISO 4762. The confirmed specification table covers M4–M36 diameters and 12–300 mm lengths. Use the specification table to select the exact variant required for quotation.
What materials and product options are available for Hexagon Socket Head Cap Screw DIN 912 ISO 4762?
Material: 40Cr Alloy Steel; Finish: Black Oxide; Drive: Hex Socket; Property Class: 12.9. Availability should be confirmed against the selected specification and order quantity.
What information should be included in a quotation request for Hexagon Socket Head Cap Screw DIN 912 ISO 4762?
Please provide the required standard, diameter or size, length, material, property class or grade, finish, quantity. A drawing or sample reference is useful when the requirement is non-standard.
