1/3Rivets （铆接系列）
Half-Hex Blind Rivet Nut
GB/T17880.2 · Carbon Steel
- Material
- Carbon Steel
- Finish
- Zinc Plated
MOQ: 5000–10000 pcs
Share
Available with the order
Order assurance
The supplier has confirmed that the options below can be agreed for this product. The exact scope is fixed in the quotation or order.Dimensional inspection report
Can be provided for the agreed inspection scope.
Bulk carton packing
Available subject to confirmed piece weight and shipping requirements.
Palletized shipment
Available when pallet size and handling requirements are confirmed.
Small boxes with outer cartons
Available when the box quantity and labels are agreed.
Buyer-specified labels
Available after label content and placement are approved.
Available options
Material
Finish
6 sizes
| Model | D₃ | L | d0 min | d0 max | g min | MOQ | Quantity and inquiry |
|---|---|---|---|---|---|---|---|
| M4*11 | M4 | 11 | 4.9 | 5.1 | 1.5 | 10000 | |
| M5*13 | M5 | 13 | 5.9 | 6.1 | 1.5 | 10000 | |
| M6*15.5 | M6 | 15.5 | 6.9 | 7.1 | 1.5 | 10000 | |
| M8*17 | M8 | 17 | 8.9 | 9.1 | 1.5 | 5000 | |
| M10*19 | M10 | 19 | 10.9 | 11.1 | 2.0 | 5000 | |
| M12*22 | M12 | 22 | 12.9 | 13.1 | 2.0 | 5000 |
GB/T17880.2 | M4*11
ModelM4*11
D₃M4
L11
d0 min4.9
d0 max5.1
g min1.5
MOQ10000
GB/T17880.2 | M5*13
ModelM5*13
D₃M5
L13
d0 min5.9
d0 max6.1
g min1.5
MOQ10000
GB/T17880.2 | M6*15.5
ModelM6*15.5
D₃M6
L15.5
d0 min6.9
d0 max7.1
g min1.5
MOQ10000
GB/T17880.2 | M8*17
ModelM8*17
D₃M8
L17
d0 min8.9
d0 max9.1
g min1.5
MOQ5000
GB/T17880.2 | M10*19
ModelM10*19
D₃M10
L19
d0 min10.9
d0 max11.1
g min2.0
MOQ5000
GB/T17880.2 | M12*22
ModelM12*22
D₃M12
L22
d0 min12.9
d0 max13.1
g min2.0
MOQ5000
Product description
Half-hex blind rivet nut with internal metric threads, manufactured from carbon steel with zinc plating. Supplied to GB/T17880.2. Available thread sizes M4 through M12 with body lengths from 11 mm to 22 mm. Mounting hole diameters and grip ranges are specified per size. Minimum order quantities are 10,000 pieces for M4–M6 and 5,000 pieces for M8–M12. For quotation, specify thread size, body length, and required quantity.
Key features
- Zinc plated finish
- Internal metric threads M4 to M12
- Half-hex body design
- Supplied to GB/T17880.2
Applications
- Automotive / Sheet Metal / Machinery / Electrical Equipment / Furniture / Solar & Energy Storage
Standard and order documents
The selected execution standard is the product basis. Published or order-specific documents are shown only when they have been confirmed for this product.
Frequently Asked Questions
What standards and sizes are available for Half-Hex Blind Rivet Nut?
Execution standard: GB/T17880.2. Use the specification table to select the exact variant required for quotation.
What materials and product options are available for Half-Hex Blind Rivet Nut?
Material: Carbon Steel; Finish: Zinc Plated. Availability should be confirmed against the selected specification and order quantity.
What quality documents can be provided for Half-Hex Blind Rivet Nut?
EN 10204 3.1 material certificate, Dimensional inspection report can be provided when the exact document scope is agreed in the quotation or order.
What are the order, packing and sample terms for Half-Hex Blind Rivet Nut?
MOQ: 5000–10000 pcs. Confirmed packing options include Bulk carton packing, Palletized shipment, Small boxes with outer cartons, Buyer-specified labels.
Where is Half-Hex Blind Rivet Nut commonly used?
Typical applications include Automotive / Sheet Metal / Machinery / Electrical Equipment / Furniture / Solar & Energy Storage. Final suitability depends on the selected material, grade, finish and operating conditions.
What information should be included in a quotation request for Half-Hex Blind Rivet Nut?
Please provide the required standard, material, finish, quantity, delivery destination. A drawing or sample reference is useful when the requirement is non-standard.
